Fall Time: 7 ns
Rise Time: 5 ns
Technology: SiC
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Qg - Gate Charge: 64 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 267 W
Vgs - Gate-Source Voltage: - 10 V, + 23 V
Typical Turn-On Delay Time: 7 ns
Typical Turn-Off Delay Time: 26 ns
Id - Continuous Drain Current: 34 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 6.5 S
Rds On - Drain-Source Resistance: 98 mOhms
Vds - Drain-Source Breakdown Voltage: 2 kV
Vgs th - Gate-Source Threshold Voltage: 3.5 V
