Basic
Sensor: IMX290
Image Sensor: 1/2.8"CMOS
Shutter: Rolling
Resolution: 1920 × 1080
Frame Rate: 22 fps
Bit Depth: 10
Mono/Color: Mono
Pixel Size: 2.9 μm × 2.9 μm
Pixel: 2.07MP
S/N Ratio: >38dB
WDR: Support DOL-HDR
Image Format: Mono8
Binning: Support
ROI: Support
Gain: 1~32
Gamma: From 0 to 4，support LUT
Exposure Time: 17.5μS~1S
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
SPC: Support
Performance
User Setting: Support two sets of user-defined configurations
Image Buffer: 256MB
Port
Port: GigE, PoE
GPIO Interface: 1x 6 pin Hirose: 1x Opto-isolated input, 1x Opto-isolated output, 1 configurable input and output
Lens Mount: C-mount
Power
Power Supply: PoE/ DC 9V~24V power supply via Hirose interface
Power Consumption: 12V≈3.3W
Structure
Product Dimensions: 29mm*29mm*42mm
Net Weight: 88 g
Environment
Storage Temperature: - 30℃~+80℃
Operating Temperature: - 30℃~+50℃
