Basic
Sensor: AR0521
Image Sensor: 1/2.5"CMOS
Shutter: Rolling
Resolution: 2592 × 1944
Frame Rate: 23 fps
Bit Depth: 12
Mono/Color: Mono
Pixel Size: 2.2 μm × 2.2 μm
Pixel: 5.0MP
S/N Ratio: 40dB
WDR: 74.3dB
Image Format: Mono8/10/10Packed/12/12Packed
Binning: Support
ROI: Support
Gain: 1~32
Gamma: From 0 to 4，support LUT
Exposure Time: 21.5μS~1S
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
SPC: Support
Performance
User Setting: Support two sets of user-defined configurations
Image Buffer: 64MB
Port
Port: GigE
GPIO Interface: 1x 6 pin Hirose: 1x Opto-isolated input, 1x Opto-isolated output, 1 configurable input and output
Lens Mount: C-mount
Power
Power Supply: DC 9V~24V power supply via Hirose interface
Power Consumption: 12V≈2.8W
Structure
Product Dimensions: 29mm*29mm*29mm
Net Weight: 60 g
Environment
Storage Temperature: - 30℃～+80℃
Operating Temperature: - 30℃～+50℃
