Basic
Sensor: IMX178
Image Sensor: 1/1.8"CMOS
Shutter: Rolling
Resolution: 3072 × 2048
Frame Rate: 18 fps
Bit Depth: 12
Mono/Color: Mono
Pixel Size: 2.4 μm × 2.4 μm
Pixel: 6.2MP
S/N Ratio: >38dB
WDR: 66dB
Image Format: Mono8/10/10Packed/12/12Packed
Binning: Support
ROI: Support
Gain: 1~32
Gamma: From 0 to 4，support LUT
Exposure Time: 25μS~1S
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
SPC: Support
Performance
User Setting: Support two sets of user-defined configurations
Image Buffer: 128MB
Port
Port: GigE
GPIO Interface: 1x 6 pin Hirose: 1x Opto-isolated input, 1x Opto-isolated output, 1 configurable input and output
Lens Mount: C-mount
Power
Power Supply: DC 9V~24V power supply via Hirose interface
Power Consumption: 12V≈3.4W
Structure
Product Dimensions: 29mm*29mm*29mm
Net Weight: 60 g
Environment
Storage Temperature: - 30℃~+80℃
Operating Temperature: - 30℃~+50℃
