Basic
Sensor: Gpixel
Image Sensor: 1.1"CMOS
Shutter: Global
Resolution: 5120 × 5120
Frame Rate: 4 fps
Bit Depth: 12
Mono/Color: Mono
Pixel Size: 2.5 μm × 2.5 μm
Pixel: 25MP
S/N Ratio: >35dB
WDR: >64dB
Image Format: Mono8/10/10Packed/12/12Packed
Binning: Support
ROI: Support
X Flip: Support
Y Flip: Support
Gain: 1~32
Gamma: From 0 to 4，support LUT
Exposure Time: 5μS~1S
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
SPC: Support
Performance
User Setting: Support two sets of user-defined configurations
Image Buffer: 256MB
Port
Port: GigE, PoE
GPIO Interface: 1x 6 pin Hirose: 1x Opto-isolated input, 1x Opto-isolated output,
Lens Mount: C-mount
Power
Power Supply: PoE/ DC 9V~24V power supply via Hirose interface
Power Consumption: 12V≈4.0W
Structure
Product Dimensions: 29mm*44mm*58mm (not including lens mount and rear case connector)
Net Weight: 100 g
Environment
Storage Temperature: - 30℃~+80℃
Operating Temperature: - 30℃~+50℃
