Basic
Sensor: IMX545
Image Sensor: 1/1.1"CMOS
Shutter: Global
Resolution: 4096 × 3000
Frame Rate: 31 fps
Bit Depth: 10
Mono/Color: Mono
Pixel Size: 2.74 μm × 2.74 μm
Pixel: 12MP
S/N Ratio: >38dB
Dynamic Range: >70dB
Image Format: Mono8/10/10Packed
Binning: Support
ROI: Support
X Flip: Support
Y Flip: Support
Gain: 1~32
Gamma: Range from 0 to 4, support LUT
Exposure Time: 1μS~1S
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
SPC: Support
Performance
User Setting: Support two sets of user-defined configurations
Image Buffer: 64MB
Port
Port: USB 3.0
GPIO Interface: 6 pin Hirose: 1 Opto-isolated input, 1 Opto-isolated output, 1 configurable input/output without opto isolation
Lens Mount: C
Power
Power Supply: Power supply via USB connector /DC power supply by Hirose connector, with voltage range from 9V to 24V
Power Consumption: ≈4.1W
Structure
Product Dimensions: 29mm × 29mm × 29mm (not including rear case connector)
Net Weight: 60g
Environment
Storage Temperature: - 30℃~+80℃
Operating Temperature: - 30℃~+50℃
