AC Input
Voltage: 220Vac (±15%)
Phase: single phase
Frequency: 47～63Hz
Max. current: 3.3A
AC Output
Max. power: 300VA
Max. voltage: 300V
Output phase: single phase
Max current(rms): 3A
Max current(peak): 9A
Frequency: 45 ～ 500Hz
Phase: 0 ～ 359.9°
T.H.D: ≤0.3% at 50/60Hz ; ≤1% at 45～500Hz
Crest factor: 3
Power regulation: ≤0.06%
Load regulation: ≤0.15%
Voltage(VAC)
Resolution: 0.1V
Accuracy: ±(0.2% +0.2%×F.S.)
Frequency
Resolution: 0.1Hz
Accuracy: ±0.1%
Phase angle
Resolution: 0.1°
Accuracy: 0.5°
DC bias: 20mV
Efficiency: 73% (typical)
DC Output
Max. output power: 300W
Max. output voltage: ±400V
Max. output current: ±3A
Voltage(VDC)
Accuracy: ±(0.2%+0.2%×F.S.)
Dynamic response: ≤0.5ms(Full load of 10~90%)
Other
Dimension: 255mm (W)x 110mm (H) x 493.9 (D) mm
Weight: 8.05 KG
