Jeiotech SK-71 Dual-Action Shakers

Name: Jeiotech SK-71 Dual-Action Shakers
Brand: JEIOtech

ManufacturerJEIOtech(View more products from this manufacturer)

ModelSK-71

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Model: SK-71
Manufacture: Jeiotech
Origin: Korea
warranty: 12 months

Control system Feedback control PID
Motion type Orbital or Reciprocating motion selectable
Frequency(RPM) 10 to 300
Timer Run time: 10 min to 999 hr 59 min 59sec
Forward & Backward, Pause: 10 sec to 59 min 59 sec
Orbit size (mm/inch dia.) 30, 40, 50, 60, 70mm
Available - Standard 30/1.2
Overall (W×L×H)(mm/inch) 820×610×170 mm
Net weight(Kg/lbs) 50kg
Electrical Requirements (230V, 50/ 60Hz) 0.2A
Cat. No. AAH31305K

Operating Features

Microprocessor PID control
Wide speed range: 10 ~ 300 rpm
Dual shaking actions: orbital or reciprocating
Additional shaking modes: Forward (clockwise rotation), Backward (counterclockwise rotation), and Pause
Multi-step Programming of Shaking Operations:
- Run time: 10 sec to 999 hr 59 min 59 sec.
- Forward/Backward/Pause modes: 10 sec to 59 min 59 sec.
Maximum orbit diameter
- 40mm (1.6″) for SK-300, 600
- 70mm (2.8″) for SK-71
Bright LED displays with touch-sensitive keypad

Constructional Features

Equipped with a maintenance-free direct drive BLDC motor to generate smooth, quiet, uniform, and yet powerful shaking motion required for high-speed applications and heavy workloads.
Special acceleration and deceleration circuitry:
- Stopping the shaking table always at the same position allowing for automated dosing or sampling.
- Providing smooth start and smooth stop preventing chemical spills from flasks or test tubes.
Low-profile design minimizing vibration or sliding caused by the high speed shaking motion.
Chemicals-resistant and durable construction
Various accessories

Model		SK-300	SK-600	Sk-71
Shaking system	Motion type	Orbital or Reciprocating motion selectable
	Frequency(RPM)	10 to 300
	Timer	Run time: 10 min to 999 hr 59 min 59sec Forward & Backward, Pause: 10 sec to 59 min 59 sec
	Orbit size (mm/inch dia.)	20, 30, 40 / 0.8, 1.2, 1.6 Available - Standard 30/1.2		30, 40, 50, 60, 70/ 1.2, 1.6, 2.0, 2.4, 2.8 Available - Standard 30/1.2
	Recip stroke length (mm/inch)	20, 30, 40 / 0.8, 1.2, 1.6 Available - Standard 30/1.2		30, 40, 50, 60, 70/ 1.2, 1.6, 2.0, 2.4, 2.8 Available - Standard 30/1.2
Dimensions	Platform (W×L),(mm/inch)	350×350 / 13.8x13.8	450×450 / 17.7x17.7	755×481 / 29.7x18.9
	Overall (W×L×H)(mm/inch)	410×490×160 / 16.1x19.3x6.3	510×595×160 / 20.1x23.4x6.3	820×610×170 / 32.3x24.0x6.7
	Net weight(Kg/lbs)	24.0 / 52.9	29.0 / 63.9	50.0 / 110.2
Electrical Requirements (230V, 50/ 60Hz)		0.2A	0.2A	0.2A
Cat. No.		AAH31105K	AAH31205K	AAH31305K
Electrical Requirements (120V, 50/ 60Hz)		0.4A	0.4A	0.4A
Cat. No.		AAH31106U	AAH31206U	AAH31306U
