X axis travel: 1800 mm
Y axis travel: 900 mm
Z axis travel: 800 mm
Spindle nose to table surface: 880 mm
Spindle center nose to column: 150 - 950 mm
Table work area: 2200 x 810 mm
Dimension of T-slot: CD 125 x 18 x 7T
Max. table load: 2000 kg
Spindle taper / Bore diameter: BT50
Driving method: Gear Head
Spindle motor-cont / 30 min: 25 HP (Mitsubishi or Fanuc)
Spindle speed: 6000 rpm
Rapid feed rate - X / Y / Z: 20 x 20 x 15 m/min
X / Y / Z ball screw: 50 x 12B2 (dia. x pitch)
Max. tool length: 250 mm(9.8") x 89 mm(3.5")
Max. tool weight: 15 kg / 33 lbs
Number of tools: 24 pcs
Tool exchanging time: Bi-direction & Min Path
Gear ratio: 1:4.2
Bearings front: NN3018 (Ø90)
Bearings rear: NN3016 (Ø80)
Bearings lubrication: Grease
Preload: Rigid
Clamping force: 2400 kg
Coolant: Oil
Coolant requirement: 1500 keal/h
Min / Max. air pressure: 4 kg / 6cm²
Coolant tank capacity: 520 L
Net weight: 18200 kg
Gross weight: 18700 kg
Floor space requirement (L x W x H): 420 x 270 x 320 cm
Packing size (L x W x H): 570 x 391 x 375 cm
Container: 1 x 40" FR
