Dimensions and volumes:
Dimensions (W × L × H): 13 x 19.3 x 18.5 in.
Filling volume: 8.5 ... 12 l
Weight: 26.2 lbs
Pump connections: M16x1 male
Barbed fittings inner diameter: 8/12 mm
Temperature values:
Working temperature range: +20 ... +200 °C
Temperature stability: ±0.01 °C
Setting the resolution of the temperature display: 0.01 °C
Temperature display resolution: 0.01°C
Ambient temperature 1: +5 ... +40 °C
Performance values: 230V/50Hz (Schuko Plug - CEE 7/4 Plug Type F)
Heating capacity: 2 kW
Pump capacity flow pressure: 8 ... 27 l/min
Circulation capacity pressure: 1.5 ... 10.2 psi
Viscosity max.: 50 cSt
Power consumption: 10 A
Bath:
Bath tank: Stainless steel
Bath cover: integrated
Usable bath opening (W x L / D): .8.7 x 5.9 / 7.9 in.
Other
Classification: Classification III (FL)
Pump function: Pressure Pump
Pump type: Immersion Pump
Electronics
Interfaces: Alarm output optional / REG/EPROG optional / RS232 optional / Standby-Input optional / USB
External pt100 sensor connection: integrated
Integrated programmer: 8x60 steps
Temperature control: PID3
Absolute temperature calibration: 3 Point Calibration
Temperature display: 3.5" TFT Display
Temperature setting: Shaft Encoder
Electronic Timer (h:min): 00:00 ... 99:59
