KEITHLEY 2260B-800-2 Programmable DC Power (800V, 2.8A, 720W)

OUTPUT RATING
Voltage 0~800V
Current 0–2.88 A
Power 720 W
RIPPLE AND NOISE (Noise bandwidth 20 MHz, ripple bandwidth 1 MHz)
CV p-p 200 mV;
CV rms 30 mV;
CC rms 10 mA
PROGRAMMING ACCURACY
Voltage : 0.1% + 400 mV
Current: 0.1% + 4 mA
READBACK ACCURACY
Voltage: 0.1% + 400 mV
Current: 0.1% + 4 mA
PROGRAMMING RESOLUTION (by PC Remote Control Mode)
Voltage: 14mV
Current: 1 mA
MEASUREMENT RESOLUTION (by PC Remote Control Mode)
Voltage: 14 mV
Current: 1 mA
- Accessories Supplied
2260B Basic Accessory Kit
(for 36V and 80V models)
2260B-010 Basic Accessories
Kit (for 250V/800V Series)
Quick Start Guide
Documentation CD with Manuals
and Software Drivers
Test Lead Set (for 36V
and 80V models)
2260-009 Test Lead (for
250V/800V models)
USB Cable
Power Cord
Certificate of Traceable Calibration

Download datasheet
