Nominal Flow Rate
@ 850 kg/m3: (Pressure Drop max. 2 bar)
65 kg/h @ 30 cSt [2.4 lb/min @ 30 cSt]
Pressure rating: 414 bar [6,000 psi]
Accuracy
Flow: ±0.2 % of flow rate
Mass Repeatability: ±0.075 % of flow rate
Zero Stability: 0.34 kg/h [0.16 kg/h] 0.012 lb/min [0.005 lb/min]
Temperature: ±1 °C ±0.5 % of flow rate [±1,8 °F ±0.5 % of flow rate]
Operating conditions-process
Process Temperature Range: -40 °C ... +100 °C [-40 °F ... +212 °F]
Medium: Liquid
Pressure Effect on Sensitivity: 0.0002 % / bar [0.000014 % / psi]
Operating conditions-environment
Ambient Temperature: -40 °C ... +70 °C [-40 °F ... +158 °F]
Relative Humidity: max. 95 %
Materials (Wetted Parts)
NACE MR0175/MR0103
Tubes: 1.4404 [AISI 316L]
Case: 1.4404 [AISI 316L]
Flow Splitter: 1.4404 [AISI 316L]
Burst protection
Rupture Disc: G1/2”
Connectivity
Flow Meter: 3/8” Autoclave (MP)
Signal Cable Connection (For triple Ex approval (Ex3)): Push-Pull connector
