System dynamic range (spec): 10 Hz IF bandwidth
At 4 GHz: 115 dB
At 20 GHz: 105 dB
At 40 GHz: -
Maximum output power (spec)
At 4 GHz: +8 dBm
At 20 GHz: +4 dBm
At 40 GHz: -
Power sweep range (typ.)
At 4 GHz: -60 to +7 dBm
At 20 GHz: -60 to +7 dBm
At 40 GHz: -
Test port noise floor (spec)
At 4 GHz: -107 dBm
At 20 GHz: -101 dBm
At 40 GHz: -
Receiver compression at test port (spec)
At 4 GHz: 0.2 dB (mag) / 5 degree (phase), at +8 dBm input power at test port
At 20 GHz: 0.2 dB (mag) / 5 degree (phase), at +4 dBm input power at test port
At 40 GHz: -
Trace noise (spec)
At 4 GHz: 0.0015 dB rms / 0.01 degree rms
At 20 GHz: 0.003 dB rms / 0.03 degree rms
At 40 GHz: -
Temperature stability (typ.)
At 4 GHz: 0.005 dB/deg.C (mag) / 0.1 degree/deg.C (phase)
At 20 GHz: 0.02 dB/deg.C (mag) / 0.4 degree/deg.C
(phase)
At 40 GHz: -
External PC system requirements
Operating systems: Windows 10 (64-bit)
Available memory: 16 GB recommended, 4 GB minimum
Available disk space: 4 GB minimum
Display resolution: 1024 x 768 minimum
Connection with VNA: Thunderbolt 3 and Thunderbolt 4
Recommended CPU: Intel Core i7 10th Generation or later recommended
Instrument drivers
Keysight IO: Libraries Keysight IO Libraries Suite 2022 Update 1 (18.2.28014.7) or later
Rear panel information
Thunderbolt 3 Ports: USB Type-C, 2 ports (for connection with a host PC)
USB Ports: Type A female (USB 2.0 only), 2-ports (for connection with USB peripherals)
Include: P9373B-001 Vector network analyzer activation software for P9373B
