Input voltage: 100 VAC ~ 240 VAC, 50 Hz ~ 60 Hz, single phase
Output power: 800 W
Output voltage: 240V
Output current: 10 A
Voltage:
Settable: max 252 V
Setting accuracy: ± (0.05 % of set + 0.05 % of rating)
Ripple noise: 100 mV p-p
Current:
Settable: max 10.5A
Setting accuracy: ± (0.5 % of set + 0.1 % of rating)
Ripple noise: 24 mA
Display Functions:
+ Voltage: max 99.99, accuracy: ± (0.2 % of reading + 5 digit)
+ Curent: max 999.9, accuracy: ± (0.5 % of reading + 8 digit)
+ Power: max 9999
Maximum internal resistance that can be set: 18 Ω
Protection functions: Overvoltage, Overcurrent, Overheat, Power limit, shutdown
Other funtions: Sequence, Output-on/off delay, Soft start/stop, CONFIG shortcut, Synchronized operation
Control functions: VPGM, IPGM, OUTPUT ON/OFF, SHUT DOWN, ALM CLR
Interface: RS232C, USB & LAN
Accessories: Chasis connection short bar, output terminal M4 screws (2 pcs.), output terminal cover, packing lisst, safety information, CD-ROM, Quick Reference, Power cord,...
