Gain: 3.3 dBi
VSWR: 1.5:1
Style: T-Bar Flex
Width: 8 mm
Height: 0.12 mm
Length: 40 mm
Impedance: 50 Ohms
Cable Type: 100 mm RF1.13
Application: Access Point, Cellular, Embedded Design, Gateway, Handheld, Healthcare, Headsets, Industrial Devices, M2M, OBD-II, Smart Grid, Tablets, Telematics, Tracking
Cable Length: 200 mm
For Use With: Agriculture, Automotive, Bluetooth, Digital Signane, Healthcare, Smart Home, WiFi Applications, WLAn, Zigbee
Polarization: Linear
Power Rating: 500 mW
Mounting Style: Adhesive Mount
Electrical Type: Embedded
Number of Bands: 1 Band
Center Frequency: 2.4 GHz
Mechanical Style: PCB Trace
Maximum Frequency: 2.485 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Antenna Connector Type: U.FL
Protocol - WiFi - 802.11: WiFi, WLAN
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
