Gain: 3.2 dBi, 4 dBi, 4 dBi, 3.4 dBi, 4.7 dBi, 4.1 dBi, 4.1 dBi, 4.2 dBi, 4 dBi, 3.4 dBi
VSWR: 2.5
Style: Sharkfin
Width: 84 mm
Height: 95 mm
Length: 130 mm
IP Rating: IP67
Impedance: 50 Ohms
Cable Type: 610 mm LMR-195M
Application: Bluetooth, LTE, GSM 850/900, GSM 1800/1900, UMTS/WCMDA (3G)
Unit Weight: 343 g
Cable Length: 0.61 m
For Use With: Bluetooth Dvices, LTE, GSM 850/900, GSM 1800/1900, UMTS/WCMDA (3G)
Polarization: Linear - Vertical
Power Rating: 50 W
Mounting Style: Panel Mount
Number of Bands: 10 Band
Center Frequency: 657.5 MHz, 761 MHz, 859 MHz, 920 MHz, 1450 MHz, 1785 MHz, 1920 MHz, 2045 MHz, 2400 MHz, 2600 MHz
Mechanical Style: Module
Maximum Frequency: 2.7 GHz
Minimum Frequency: 617 MHz
Termination Style: Connector
Antenna Connector Type: SMA Male
Protocol - WiFi - 802.11: 802.11 b/g/n, WLAN
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 30 C
Protocol - Cellular, NBIoT, LTE: 3G, Cellular (NBIoT, LTE), GSM, UMTS, WCMDA
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
