Measurement: X-ray fluorescence analysis
Determination method: Energy dispersion type
Determination of the object: Solid, liquid, powder
Range of measurement: Mg-U
Sample room size: 368*304*78mm
Maximum sample weight: 2.5 kg
Open way: The automatic control
X-ray generating department
X-ray tube: High power side window X-ray tube
Voltage: 5-50KV
Current: 0-1000μA
Cooling way: Air cooling
Collimator: 5mm，3mm，1mm，0.5mm
Detector
Type: BOOST Si-PIN
Cooling way: Peltier cooling
Measurement situation: Atmosphere, Vacuum (optional), Helium (optional)
Sample observation: 5-megapixel high-definition industrial camera
Data processing department
PC processor (CPU): I3-7100, same dominant frequency or above
Memory (RAM): DDR4 4G memory or above
Hard disk capacity (ROM): 1TB HDD or 256GB SSD or above
OS: Windows 10
Environment setup
Temperature conditions: 10°C ~ 35°C
Relative humidity: 40~70%(no dew)
Power supply: 220VAC
Rated power: 100W
Size of the host: 570*402*400mm
Host weight: 47kg
