Specifications
Flow range:90-2700ml/min
Speed range:300-3000rpm/min
Speed resolution:1rpm/min，accuracy 3%
Adjusting way:Keypad
Display mdoe:4 LED digital display
Power supply:AC 88-264V 50Hz/60Hz（standard）
consumption:<150W
Working envronment:Environment 0~ 40℃ humidity <80%
Dimension size:320X150X 237 mm
Drive weight:5.5kg
IP standard:IP31
| Pump head | Gear materal | Pressure (MPa) | Flow range (MPa) | Liquid temperature℃ |
| MS204XD0PT00000 | PEEK | ≤1.4 | 90-900 | -45-120 |
| MS209XD0PT00000 | PEEK | ≤0.9 | 180-1800 | -45-120 |
| MS213XD0PT00000 | PEEK | ≤0.8 | 270-2700 | -45-120 |
