- Bandwidth: 50 MHz
- Channels: 2
- Waveforms: Sine, Square, Ramp, Pulse, Noise, Arbitrary: Stairup, Stairdown, Positive Pulse, Negative Pulse,
Up Ramp, Down Ramp, Sinc, Gaussian, LogFall, LogRise, Sqrt, TwoTone, etc
- Sine: 1 μHz - 50 MHz
- Square: 1 μHz - 25 MHz
- Pulse: 500 μHz - 5 MHz
- Triangle/Ramp: 1 μHz - 300 kHz
- Arbitrary Waveforms: 1 μHz - 5 MHz
- Modulation: AM, PM, FM, ASK, PSK and FSKduty-cycle square waveform
- External Clock: 10 MHz ± 100 Hz
- Sync Output: TTL compatible
- Trigger Output: TTL compatible
- External Trigger: TTL compatible
- Output Amplitude - CH1: 2 mVpp - 6 Vpp
- Output Amplitude - CH2: 2 mVpp - 20 Vpp
- Display: 3.5 inch TFT-LCD, 320 x 240, RGB
- Dimensions (H x W x D): 105 mm x 229 mm x 281 mm (4.1” x 9.0” x 11.1”)
- Weight: 2.6 kg (5.7 lbs)
- Power: 100 - 240 Vrms (± 10%), 50 / 60 Hz)
- Included with Standard Configuration
+ Power Cable for the Destination Country
+ USB 2.0 Cable Type A to B (Black, 1 m)
+ USB to GPIB Converter
+ Getting Started Manual
+ Performance Certificate
+ Declaration of Conformity
+ WaveStation PC Software CD
+ Product Registration Card
Accurate waveform creation with high resolution, fast sample rate, and low distortion
5 basic functions and over 40 built-in arbitrary waveforms
Built-in modulation capabilities include AM, PM, FM, ASK, PSK and FSK
Quickly access functions from the front panel, view created waveforms and waveform parameters on the display
USB and GPIB for simple remote control, automation and transferring data
Easily create and edit waveforms on the PC and quickly transfer to the WaveStation
