Gender: Pin (Male)
Polarity: Standard
Impedance: 50 Ohms
Isolation: Non-Isolated
RF Series: LC
Body Style: Straight
Cable Type: HPL-1200
Body Finish: Copper
Orientation: Straight
Body Material: Brass
Mating Cycles: 500 Cycles
Mounting Style: Cable Mount / Free Hanging
Voltage Rating: 2330 Vrms
Contact Plating: Silver
Contact Material: Beryllium Copper, Brass
Maximum Frequency: 1 GHz
Minimum Frequency: DC
Termination Style: Twist On
Insulation Resistance: 10 GOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
