Gain: 0.1 dBi
VSWR: 4.1
Width: 8.2 mm
Height: 0.1 mm
Length: 12.4 mm
Bandwidth: 2.4 GHz
Impedance: 50 Ohms
Cable Type: Coaxial
Wavelength: 1/2 Wave
Application: 2.4 GHz ISM, Bluetooth, ZigBee
Cable Length: 100 mm
Polarization: Linear
Power Rating: 2 W
Mounting Style: Adhesive Mount
Electrical Type: Dipole
Number of Bands: 1 Band
Mechanical Style: Rectangular
Maximum Frequency: 2.5 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Antenna Connector Type: MHF4
Protocol - WiFi - 802.11: 802.11, WiFi
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
