Gain: - 2.0 dBi
VSWR: 1.7
Style: RA Straight
Width: 18.7 mm
Length: 97.7 mm
Diameter: 10.5 mm
Bandwidth: 150 MHz
Impedance: 50 Ohms
Wavelength: 1/4 Wave
Application: Low Power Wide Area Applications, IoT Devices, Remote Control, Monitoring, Sensing
Unit Weight: 13.256 g
Polarization: Linear
REACH - SVHC: Details
Mounting Style: Panel Mount
Electrical Type: Monopole
Number of Bands: 1 Band
Center Frequency: 916 MHz
Mechanical Style: Whip
Ground Plane Size: 102 mm x 102 mm
Maximum Frequency: 990 MHz
Minimum Frequency: 840 MHz
Termination Style: Connector
Protocol - Sub GHz: RFID, ISM
Antenna Connector Type: RP-SMA Male
Protocol - WiFi - 802.11: LoRaWAN, Sigfox
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), GSM, UMTS
