Gain: 4.2 dBi
VSWR: 2.4
Style: Tilt/Swivel
Width: 29.4 mm
Length: 72 mm
Diameter: 0.95 mm
Impedance: 50 Ohms
Wavelength: 1/4 Wave
Application: Wireless Applications, U-NII, ISM Applications, IoT Devices, Smart Home Networking, Sensing, Remote Monitoring
Polarization: Linear
Power Rating: 5 W
REACH - SVHC: Details
Mounting Style: Panel Mount
Electrical Type: Monopole
Number of Bands: 3 Band
Center Frequency: 2.4 GHz, 5 GHz, 6 GHz
Mechanical Style: Whip
Ground Plane Size: 150 mm x 90 mm
Maximum Frequency: 7.125 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM, U-NII
Antenna Connector Type: RP-SMA Plug
Protocol - WiFi - 802.11: 802.11 b/g/n/ac/ax, WiFi 4, WiFi 5, WiFi 6, WiFi 6E
Maximum Operating Temperature: + 130 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/4G/5G, Cellular (NBIoT, LTE)
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
