Number of poles: 3P
Frame size: 800AF
Line voltage: AC, DC
Rated voltage (Ue): 500VDC, 690VAC
Rated frequency: 50Hz, 60Hz
Current rating adjustable (Ir): No
Rated current (In): 630A
Characteristics curves: C
Rated short-circuit breaking capacity (Icu): 8kA at 690VAC, 35kA at 480VAC, 50kA at 415VAC, 65kA at 380VAC, 75kA at 220VAC, 20kA at 500VDC, 20kA at 250VDC, 35kA at 500VAC, 50kA at 460VAC, 75kA at 250VAC
Service breaking capacity - Ics (% Icu): 100%
On/Off control type: Handle toggle
Mounting method: Surface mounting
Connection type: Screw terminals
Approx. weight: 8.8kg
Overall width: 210mm
Overall height: 280mm
Overall depth: 145mm
