Capacity: 50kg
Material: Stainless Steel
Rated Output: 2 ± 10%mV / V
Zero Balance: ± 2%F .S.
Non-linearity: ± 0.196 F .S.
Hysteresis: ± 0.1% * F .S
Repeatability: ± 0.1% * F .S.
Creep (30min): ± 0.1% * F .S.
Temp. Effect on Output: ± 0.1%F .S./10°C
Temp. Effect on Zero:± 0.1% F .S./10°C
Input Impedance: 350 ± 10Ω
Output Impedance: 350± 5Ω
Insulation: >= 5000MΩ / 100 * VDC
Recommended Excitation: 3 ~ 5v
Operating Temp. Range: -20 ~80°C
Compensated Temp. Range: 10 ~60 °C
Safe Overload: 120%
Maximum Overload: 150%
Cable Specifications: 0.2 * 3m
Protection Class: IP50
