Load capacity: 750 lbF [3.4 kN]
Maximum travel: 14.2 in[360 mm]
Speed range: 0.001 - 60 in/min[0.02 - 1,525 mm/min]
Load sampling rate: 20.000 Hz
Data acquisition rate: 1.000 Hz
Speed accuracy: ±0.2% of setting
Distance accuracy: ±0.002 in [0.05 mm]
Distance resolution: 0.0005 in / 0.01 mm
Limit switch repeatability: ±0.001 in / 0.03 mm
Overload protection: Motor stops at 120% of full scale of the force sensor
Power: Universal input 100-240 VAC, 50/60 Hz, 300W
Fuse type: 4A, 3AG, SLO BLO
Weight: 149 lb [68 kg]
