Gain: 3.8 dBi
VSWR: 1.4:1
Style: Puck
Length: 14.7 mm
Diameter: 54 mm
IP Rating: IP67, IP69K
Impedance: 50 Ohms
Cable Type: 3 M RG174
Application: Navigations Systems, Telematics Systems, IoT, Automotive Connectivity, Multimedia, Fleet Management, HD Video & Audio Streaming
Polarization: Linear
Power Rating: 25 W
Mounting Style: Magnetic Mount
Frequency Range: 2.41 GHz to 2.49 GHz
Number of Bands: 1 Band
Center Frequency: 2.4 GHz
Mechanical Style: Module
Maximum Frequency: 2.49 GHz
Minimum Frequency: 2.41 GHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: SMA Male
Protocol - WiFi - 802.11: WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
