Gain: 1 dBi, 1 dBi, 1 dBI, 2 dBi, 2 dBi
VSWR: 2:1, 3.7, 3.5 , 3
Style: Puck
Width: 39 mm
Height: 1.4 mm
Length: 48 mm
IP Rating: IP67
Impedance: 50 Ohms
Cable Type: 1 M RG174/U
Application: Asset Tracking, Telematics, Container, Logistics, Automotive, Industrial Applications, IoT Applications
Unit Weight: 40 g
Cable Length: 1 m
Polarization: Linear
Mounting Style: Adhesive Mount
Number of Bands: 2 Band
Center Frequency: 1.57541 GHz, 1.602 GHz, 829 MHz, 1.94 GHz, 2.495 GHz
Mechanical Style: Module
Maximum Frequency: 2.69 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Antenna Connector Type: SMA / FAKRA
Protocol - GPS, GLONASS: GLONASS, GPS
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), GSM, UMTS
