Max. single blow energy (EPTA): 2.3 J
Maximum impact rate: 5400 bpm
Rated input power: 800 W
Drill-Ø concrete with hammer drills: 26 mm / 1 "
Drill-Ø masonry with core bits: 68 mm / 2 11/16 "
Drill-Ø steel: 13 mm / 1/2 "
Drill-Ø soft wood: 30 mm / 1 3/16 "
No-load speed: 0 - 1150 rpm
Revolutions at rated load: 960 rpm
Bit retainer: SDS-plus
Collar diameter: 43 mm / 1 11/16 "
Weight (without power cable): 2.9 kg / 6.4 lbs
Cable length: 4 m / 13 ft
Vibration
Hammer drilling concrete: 13.7 m/s²
Uncertainty of measurement K: 1.5 m/s²
Chiseling: 15 m/s²
Uncertainty of measurement K: 1.5 m/s²
Noise emission
Sound pressure level: 87 dB(A)
Sound power level (LwA): 98 dB(A)
Uncertainty of measurement K: 3 dB(A)
Delivery
Hammer chuck for tools with SDS-plus shank end
Plastic carry case
Side handle
Drilling depth guide
Accessories
DRILLING/CHISELLING
SDS-plus drill/chisel bits, Wood drill bits, Metal drill bits, Hole saws, Universal drill bits, Diamond drill bits, Drill bit assortments, Core bits, Further accessories for (impact) drills, Further accessories for rotary and chipping hammers
ACCESSORY SETS/SPECIALS
Bit sets, Drill bit sets, Chisel bit sets
CHUCKS
Geared chucks, Chuck keys
SCREWDRIVING/FIXING
Screwdriving bits, Screwdriving bit sets, Bit holders, Screw-type angle attachments
OTHER ACCESSORIES
Case systems, Occupational safety
Datasheet
Features
Combination hammer with 3 functions: hammer drilling, drilling and chiselling
Vario (V)-Electronics for working at customised speeds to suit various application materials
Electronic soft start for precise spot-drilling
High performance hammer action, precisely mounted in a housing made of aluminium alloy: long-lasting and robust
Metabo S-automatic safety clutch: mechanical decoupling of the drive for safe working should the drill stop unexpectedly
Lockable switch for comfortable working in continuous operation
