Width: 3.62 mm
Height: 4.62 mm
Length: 4.71 mm
Output Type: Active Low, Push-Pull
Unit Weight: 453.600 mg
Manual Reset: No Manual Reset
Qualification: AEC-Q100
Mounting Style: Through Hole
Watchdog Timers: No Watchdog
Reset Delay Time: 350 ms
Threshold Voltage: 4.625 V
Chip Enable Signals: No Chip Enable
Power Fail Detection: No
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 1 V
Overvoltage Threshold: 4.75 V
Undervoltage Threshold: 4.5 V
Battery Backup Switching: No Backup
Operating Supply Current: 60 uA
Number of Inputs Monitored: 1 Input
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
