Fall Time: 25 ns
Rise Time: 30 ns
Technology: SiC
Configuration: Full Bridge
Mounting Style: Screw Mount
Transistor Polarity: N-Channel
Vf - Forward Voltage: 1.5 V at 60 A
Vr - Reverse Voltage: 1.2 kV
Pd - Power Dissipation: 560 W
Vgs - Gate-Source Voltage: - 10 V, + 25 V
Typical Turn-On Delay Time: 30 ns
Typical Turn-Off Delay Time: 50 ns
Id - Continuous Drain Current: 150 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 16 mOhms
Vds - Drain-Source Breakdown Voltage: 1.2 kV
Vgs th - Gate-Source Threshold Voltage: 1.8 V
