Max Cutting Diameter: Φ130 mm
Cutting Method: Chop cutting, flat push cutting, sweep cutting
Cutting Speed: 0.01-1mm/s（adjustment step 0.01）
Reset Mode: Automatic
Control System: Siemens PLC 7”touch LCD screen
Rotation Speed: 2800rpm
Max Stroke: Z-axis 130mm；Y-axis 200mm；X-axis 100mm
Working Table Size: 128*320mm, 180*320mm
Cutting Disc: 350*2.5*32mm
Motor: 4kw
Voltage: AC380V±10% , 50-60Hz
Machine Dimension: 1350*1100*1750mm（L×W×H）
Net Weight: 707.5kg
Standard Delivery
Machine Mainframe(with clamp): 1 set
Water Tank (with water pump): 1 pc
Cut-off Wheel 400×4×32mm: 2 pcs
Clamp: 1pc
Outlet Pipe: 1pc
Inlet Pipe: 1pc
Pipe Hoop: 2 pcs
Wrench: 3 pcs
Optional Delivery
Aluminum Oxide Cut-off Wheels: A060/A050/A030
Cutting Fluid: CF-1L/CF-4L
Vertical Fixture: MS-VF
