Gain: 17.5 dB
Technology: Si
Mounting Style: SMD/SMT
Test Frequency: 30 GHz
Input Return Loss: 17.2 dB
NF - Noise Figure: 4.8 dB
Moisture Sensitive: Yes
Number of Channels: 1 Channel
Operating Frequency: 2 GHz to 30 GHz
Supply Voltage - Max: 5.25 V
Supply Voltage - Min: 4.75 V
Pd - Power Dissipation: 1.55 W
Operating Supply Current: 92 mA
Operating Supply Voltage: 4.75 V to 5.25 V
P1dB - Compression Point: 11.5 dBm
OIP3 - Third Order Intercept: 20.6 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 45 C
