Gain: 18.2 dB
Technology: Si
Mounting Style: SMD/SMT
Test Frequency: 17 GHz
Input Return Loss: 3.2 dB
NF - Noise Figure: 1.2 dB
Number of Channels: 1 Channel
Operating Frequency: 13.5 GHz to 17 GHz
Supply Voltage - Max: 3.25 V
Supply Voltage - Min: 2.75 V
Pd - Power Dissipation: 420 mW
Operating Supply Current: 19 mA
Operating Supply Voltage: 2.75 V to 3.25 V
P1dB - Compression Point: 6.6 dBm
OIP3 - Third Order Intercept: 21 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
