Molex 172065-1012 Power Mega-Fit Vert Hdr ASSY 12 ckt 30"GOLD

Pitch: 5.7 mm (0.224 in)

Row Spacing: 5.7 mm (0.224 in)

Unit Weight: 6.728 g

Housing Color: Black

Latching Type: Top Latch

Contact Gender: Pin (Male)

Current Rating: 23 A

Mounting Angle: Straight

Mounting Style: Through Hole

Number of Rows: 2 Row

Voltage Rating: 600 VAC/DC

Contact Plating: Gold

Contact Material: Copper

Housing Material: Liquid Crystal Polymer (LCP)

Termination Style: Solder Pin

Flammability Rating: UL 94 V-0

Number of Positions: 12 Position

Termination Post Length: 3.73 mm (0.147 in)

Maximum Operating Temperature: + 120 C

Minimum Operating Temperature: - 40 C
