Gain: 2.4 dBi, 3.3 dBi, 2.6 dBi, 2.3 dBi, 3 dBi, 3.4 dBi, 3.5 dBi, 3.9 dBi
Style: T-Bar Flex
Width: 20 mm
Height: 0.1 mm
Length: 70 mm
Impedance: 50 Ohms
Cable Type: 200 mm Coax
Unit Weight: 3.575 g
Cable Length: 200 m
Polarization: Linear
Power Rating: 2 W
Mounting Style: Adhesive Mount
Electrical Type: MIMO
Number of Bands: 2 Band
Center Frequency: 2.45 GHz, 5.5 GHz
Mechanical Style: PCB Trace
Maximum Frequency: 5.85 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Antenna Connector Type: IPEX MHF
Protocol - WiFi - 802.11: WiFi
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
