1. Voltage
- Output range
+ Charge: 0V～60V
+ Discharge: 3V～60V
- Min discharge voltage: 3V
- Accuracy: ±0.02%of FS
- Resolution: 24bit
2. Current
- Output range: 3A～600A
- Accuracy(independent range): ±0.05%of FS
- CV cut-off current: 600mA
- Resolution: 24bit
3. Power
- Single channel output power: 36KW
- Whole machine output power: 72KW
4. Time
Current response time: ≤3ms
Current conversion time: ≤6ms
Min.step time: 0.1s
5. Charge/Discharge modes
- Charge/Discharge modes: CCC, CVC, CC-CVC, CPC, CCD, CVD, CPD, CRD
- Cut-off condition: Voltage, Current, ΔTime,Capacity, -ΔV
6. Simulation
- Charge: Current, Power
- Discharge: Current, Power
- Switch: Support continuous switching between charge and discharge
- Cut-off condition: Time, step line
- Stepsfile lines: 1.000.000
7. Pulse Mode
- Charge: Current, power
- Discharge: Current, Power
- Min pulse: 100ms
- Pulse counts: Up to 32
- Charge and discharge switch: supported
- Cut-off condition: Voltage,ΔTime
8. DCIR: DCIR by calculation
