Core: S08
Width: 6.4 mm
Height: 1.2 mm
Length: 6.4 mm
Unit Weight: 81.400 mg
Data RAM Size: 1 kB
Data RAM Type: RAM
ADC Resolution: 10 bit
Data Bus Width: 8 bit
Interface Type: I2C, SCI, SPI
Mounting Style: SMD/SMT
Number of I/Os: 17 I/O
Development Kit: DEMO9S08SH
Watchdog Timers: Watchdog Timer
Processor Series: S08SH
Moisture Sensitive: Yes
Program Memory Size: 16 kB
Program Memory Type: Flash
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 2.7 V
Number of ADC Channels: 12 Channel
Maximum Clock Frequency: 40 MHz
Number of Timers/Counters: 2 Timer
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
