CMRR: 90 dB
Width: 51 mm
Height: 73 mm
Length: 96 mm
Weight: 510 g
Bandwidth: 3 Hz (-3 dB)
Linearity: ± 0.05%
Gain Range: 40 to 250
Input Type: Voltage
Capacitance: 50 pF
Input Range: 10 mV to 50 mV
Output Noise: 1 µA rms @ gain 0.2 mA/mV, 1 to 100 Hz
Supply Power: 115 Vac
Output Detail: ± 10 Vdc @ 2 kΩ Load
Output Signal: Current
Impedance Input: 1000 MΩ
Impedance Output: 1 Ω
Input Resistance: 4_to_20_ma_1_to_5_vdc
Electrical Output: 4 to 20 mA
Sensor Excitation: 4 to 15 Vdc
Supply Power Note: Standard 115 Vac or optional 220 Vac ± 10% 50/60 Hz or 10 to 36 Vdc 0.7 A @ 10V, 0.17 A @ 36V at maximum excitation load
Supply Power Type: AC
Compliance Voltage: 10 Vdc
Input Bias Current: 30 nA
Common Mode Voltage: ± 15V
Loop Resistance, Max: 500 Ω
Excitation Voltage Note: Excitation Voltage Range: 4 to 15 Vdc Current Output: 120 mA max Line and Load Regulation: (0 to 100 mA) 0.05% max Output Noise: 0.5 mVrms
Temperature Coefficient: Gain: 200 ppm/°C
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -25 °C
Operating Temperature, Max: 70 °C
Operating Temperature, Min: 0 °C
