Width: 86 mm
Height: 73 mm
Length: 42 mm
Weight: 250 g
Weight Note: 250 g (8.8 oz)
Auto-Shutoff: 1 minute to 8 hours, default 5 min
Battery life: 2000 hr
Display Type: 4 Digit LED
Accuracy Note: ± 0.25% FS ± 1 digit (includes linearity, hysteresis and repeatability)
Pressure Type: Vacuum
Pressure, Max: 15 psi
Pressure, Min: 0 psi
Accuracy Class: 0.1% to 0.25%
Burst Pressure: 4x Full Scale or Maximum 10,000 psi
Proof Pressure: 2x Full Scale
Number of Digits: 4
Display Type Note: 4 digit, 0.5" H and 5 character 0.25" H alphanumeric
Materials, Wetted: 316 Stainless Steel
Pressure Accuracy: ± 0.25 %
Supply Power Note: Battery Note:2 "AA" Batteries (included)
Supply Power Type: Battery
Enclosure Material: ABS
Media Compatibility: Alcohols, Argon, Compatible Gases, Compatible Liquids, Nitrogen, Oils, Water
Overpressure Display: i---- or i -.-.-.-
Battery Size and Type: Alkaline AA
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Process Temperature, Max: 70 °C
Process Temperature, Min: 0 °C
Storage Temperature, Max: 95 °C
Storage Temperature, Min: -40 °C
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -20 °C
Material Construction Option: Standard
material-construction-option: Standard
