CMRR: 85 dB
Width: 22.5 mm
Height: 110 mm
Length: 77 mm
Weight: 142 g
Accuracy: ± 0.1 %
Mounting: DIN Rail Mount
Isolation: 700 V
Linearity: ±0.02%
Materials: Plastic
Input Type: Current
Output Value: Process
Output Signal: Voltage
Response Time: 10 ms (10 to 90%)
Supply Voltage: 22 to 26 Vdc
Impedance Input: Voltage: 1 MΩ minimum, Current: 50 Ω typical
Load Resistance: 0 to 500 Ω
Input Range Note: Maximum Input: Voltage input models, 130 VRMS; current input models, 65 mA (3.25 volts across 50 Ω input resistance)
Number of Inputs: 1
Supply Power Note: 22 to 26 Vdc (unregulated); 15 mA (models DRC-8920/21/40/41/42), 20 mA
Supply Power Type: DC
Open_Circuit Voltage: 13 V
Voltage Output Range: 0 to 10 V
Additional Features 1: Slim Housing Mounts on DIN Rail
Temperature Coefficient: Zero, ±0.5 mV/°C (0 to 10 V output models), ±0.5 microamp/°C (4 to 20 mA output models); full scale, ±100 ppm/°C typical
Storage Temperature, Max: 80 °C
Storage Temperature, Min: -40 °C
Current Measurement Range: 4 to 20 mA
Operating Temperature, Max: 55 °C
Operating Temperature, Min: 0 °C
