Accuracy: ± 1 %
Compliance: CE
Calibration: NIST 10-Point Certificate
Switch Type: SPDT NO/NC, Selectable
Display Type: LCD
Accuracy Note: ± 1% of FS at calibration temperature and pressure
Output Detail: Linear 0 to 5 Vdc (3000 Ω min load impedance); Linear 4 to 20 mA (500 Ω max loop resistance). Max noise 20 mV peak to peak (for 0 to 5 Vdc output)
Output Signal: Current, Voltage
Repeatability: ± 0.15%
Response Time: 2 sec
Switch Rating: 30 Vdc, 1A
Data Interface: RS232
Humidity Range: Up to 70%
Supply Voltage: 11 to 26 Vdc
Turndown Ratio: 50:1
Electrical Output: 4 to 20 mA, 0 to 5 Vdc
Enclosure Ratings: Inst. Level II/Poll. Degree II (IEC 60664)
Materials, Wetted: 316 Stainless Steel, Aluminum, Brass, FKM
Power Consumption: 2.4 W
Supply Power Note: Transducer Input Power: 11 to 26 Vdc, 100 mV max peak to peak output noise
Pressure Drop, Max: 0.18 psi
Response Time Note: 600 ms time constant; approximately 2 seconds to within ± 2% of set flow rate for 25 to 100% of full scale flow
Media Compatibility: Air, Gases, Nitrogen, Oxygen
Altitude Sensitivity: Deviation of up to 1% from stated accuracy, after re-zeroing
Pressure Coefficient: 0.01% FS/psi
Leak Rate Under Vacuum: less than 10^⁻9 cc He/s
Operating Pressure, Max: 500 psi
Operating Pressure, Min: 0 psi
Process Connection Size: 1/4 in
Process Connection Type: Compression Fitting
Temperature Coefficient: 0.15% FS/°C
Volumetric Flow Rate, Max: 1 SLM
Volumetric Flow Rate, Min: 0.1 SCCM
Operating Temperature, Max: 50 °C
Operating Temperature, Min: 5 °C
