Width: 1.03 in
Height: 3.5 in
Length: 1.87 in
Weight: 0.44 lb
Accuracy: ± 1.5 %
Display Type: LCD
Output Detail: 0 to 5 Vdc (2500 Ω minimum)
Output Signal: Voltage
Repeatability: ± 0.5%
Response Time: 2 sec
Supply Current: 100 mA
Supply Voltage: 12 to 15 Vdc
Turndown Ratio: 10:1
Electrical Output: 0 to 5 V
Enclosure Ratings: IP10
Materials, Wetted: 304 Stainless Steel, 316 Stainless Steel, Acetal, Aluminum, Epoxy, FKM
Pressure Drop, Max: 1 inH₂O
Response Time Note: 2 seconds (typical) to within ± 2% of actual flow rate from 25 to 100% of full scale
Media Compatibility: Air, Gases, Nitrogen, Oxygen
Pressure Coefficient: ± 0.02%/psi
Additional Features 1: Requires 20-micron filter
Leak Rate Under Vacuum: less than 10^⁻4 cc He/s
Operating Pressure, Max: 150 psi
Operating Pressure, Min: 0 psi
Process Connection Size: 1/8 in
Process Connection Type: Compression Fitting
Temperature Coefficient: ± 0.2%/°C
Volumetric Flow Rate, Max: 50 SCCM
Volumetric Flow Rate, Min: 2 SCCM
Operating Temperature, Max: 50 °C
Operating Temperature, Min: 10 °C
Material Construction Option: Aluminum
material-construction-option: Aluminum
