Shock: 1000 g, 11 ms
Bandwidth: 300 Hz (-3 dB)
Vibration: 5 to 20 Hz, 0.5" p-p; 20 to 2000 Hz, 4.2 g p-p
Cable Type: Insulated
Resolution: 0.025% of FS
Output Detail: 4 to 20 mA (3-wire) output with 18 to 30V input, 60 mA max at 75°C (167°F max)
Housing Length: 60.5 mm
Supply Voltage: 18 to 30 Vdc
Housing Diameter: 19 mm
Housing Material: Stainless Steel
Measurement, Max: 50 mm
Measurement, Min: 0 mm
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP67
Relative Humidity: 95% RH, non-condensing
Additional Features 1: Non-Contact LVIT
Temperature Coefficient: 0.015% of FS/°C
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -20 °C
