Width: 80 mm
Height: 120.65 mm
Length: 54.86 mm
Weight: 220 g
Accuracy: ± 0.02 %
Mounting: Through holes in base by 2 screws and nuts, can be mounted to DIN 46277-1 rail
Approvals: CE
Gain Range: 3.5 to 1 switched, 5 to 1 adjustable
Input Type: Voltage
Protection: Oscillator Protection: Open and short circuit protected, Output Protection: Open and short circuit protected, Supply Protection: Reverse polarity protected
Input Noise: 0 to 1.5 Hz: 1.4 µVRMS (RTI)
Input Range: 30 to 530 mV/V
Sensitivity: Transducer : 30 to 530 mV/V
Non-Linearity: Better than 0.02%
Output Detail: Output Current: 4 to 20 mA 2-wire or 0 to 20 mA 3-wire. Output Ripple:<50 µA p-p @ 10 kHz Output Filter: Cutoff frequency -3 dB @ 25 Hz second-order linearity: <0.02%
Output Signal: Current
Supply Voltage: 13 to 48 Vdc, up to 30 mA
Number of Wires: 2, 3
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP65, NEMA Type 12
Sensor Excitation: 0.9 Vrms @ 5 kHz nominal, 13 kHz switchable
Supply Power Type: DC
Temperature Coefficient: Zero: Better than 0.01% FS/°C;Gain: Better than 0.01% FS/°C
Storage Temperature, Max: 80 °C
Storage Temperature, Min: -40 °C
Operating Temperature, Max: 70 °C
Operating Temperature, Min: 0 °C
Input Electrical Connection: Screw terminals; access through 2 cable ports for wires 1 to 5 mm (0.04 to 0.2") diameter
