OMEGA PGR-45LSS-2000 All-Welded Pressure Gauge with Integral Diaphragm Seal (Gauge; 0~2000psi; 1/2"NPT Male; ±0.5%)

Name: OMEGA PGR-45LSS-2000 All-Welded Pressure Gauge with Integral Diaphragm Seal (Gauge; 0~2000psi; 1/2"NPT Male; ±0.5%)
Brand: OMEGA

ModelPGR-45LSS-2000

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Pressure Type: Gauge

Pressure Range Units: psi

Pressure Range Min: 0

Pressure Range Max: 2000

Pressure Port Type: NPT Male

Pressure Port Size: 1/2"

Accuracy Value: ±0.5%

Accuracy Class: > 0.25%

Dial Size: 4.5"

Additional Features: Integral Diaphragm Seal

Accuracy: ± 0.5% of span (grade 2A)

Case Size: 114 mm (4.5") diameter

Process Connection: ½ MNPT bottom connection

Seal Upper Material: 316L stainless steel

Diaphragm Material: 316L stainless steel

System Fill Type: DC200

Operating Temperature: 143°C (225°F)

See more detail information in the Datasheet

Datasheet
