Weight: 85 g
Accuracy: ± 1 %
Hysteresis: 0.10% FS
Accuracy Note: ± 1% BFSL at constant temperature (includes linearity, repeatability and hysteresis)
Output Signal: Voltage
Pressure Type: Differential
Pressure, Max: 0.25 inH₂O
Pressure, Min: -0.25 inH₂O
Accuracy Class: > 0.25%
Proof Pressure: Up to 10 psi
Supply Voltage: 9 to 30 Vdc
Thermal Effect: ± 0.06%/°C
Linearity Error: ± 0.98%
Sensing Element: Capacitive
Compatible Meters: DP41-E, DP25B-E, DP-7700
Electrical Output: 0.2 to 5.2 V
Output Resistance: <100 Ω
Supply Power Note: 9 to 30 Vdc unregulated
Enclosure Material: Fire-retardant glass-filled polyester
Zero/Balance Error: Set to ± 50 mV
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen
Repeatability Error: ± 0.05% FSO
Electrical Connection: Screw Terminal
Process Connection Note: 3 ⁄16" OD pressure fitting for 1 ⁄4" tube
Process Connection Size: 3/16 in
Process Connection Type: OD pressure fitting
Compensated Temperature, Max: 65 °C
Compensated Temperature, Min: -18 °C
Span Setting Adjustable Range: Set to 5 Vdc ± 50 mV
