Shock: 50 g, 11 ms half-sine
Weight: 200 g
Accuracy: ± 0.08 %
Bandwidth: DC to 1 kHz
Stability: ± 0.1%
Vibration: 5-2000-5 Hz, 30 minute cycle,Curve L, Mil-Spec 810 figure 514-2-2, vertical and horizontal axis
Cable Length: 2 m
Accuracy Note: 0.08% BSL linearity, hysteresis and repeatability combined Thermal Accuracy: ± 0.50%(Span &Zero)
Output Signal: Digital
Pressure Type: Differential
Pressure, Max: 30 psi
Pressure, Min: 0 psi
Response Time: <1 ms
Accuracy Class: < 0.1%
Proof Pressure: 4x Full Scale up to 3000 psi
Stability Note: Long Term Stability (1-Year): ± 0.1% FS typical
Pressure Cycles: 1 million, minimum
Electrical Output: USB
Materials, Wetted: 316L Stainless Steel
Media Compatibility: Air, Alkaline solutions, Any, Argon, Carbon dioxide, Dilute Acids, Gases, Helium, Hydraulic Oil, Hydrogen, Light Oil, Liquids, Nitrogen, Non-corrosive Dry Gasses, Oil, Oxygen, Solvents, Steam, Water, Water-based fluids
Proof Pressure Note: 4 times range
Line/Static Pressure: 500 psi max
Additional Features 1: None
Electrical Connection: Cable
Insulation Resistance: 100 MΩ
electrical-connection: Cable
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Compensated Temperature, Max: 85 °C
Compensated Temperature, Min: -29 °C
Positive Side differential wetted materials: 316L stainless steel
Negative Side differentional compatable fluids or gasses: Clean, Dry, Non-ionic gases
