Width: 101.6 mm (4 in)
Height: 41.4 mm (1.63 in)
Length: 351.2 mm (13.827 in)
Industry: Industrial
Approvals: CAN/CSA, CE, UL, VDC
Compliance: CAN/CSA, CE, UL, VDC
Efficiency: 95 %
Unit Weight: 2.306 kg
Output Power: 2.25 kW
Input Voltage: 100 VAC to 120 VAC, 220 VAC to 240 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 66 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVrms
Number of Outputs: 1 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 43.3 A
Output Voltage-Channel 1: 18 VDC to 53 VDC
Operating Temperature Range: - 40 C to + 55 C
Maximum Operating Temperature: + 55 C
Minimum Operating Temperature: - 40 C
