Logic Family: NL27WZ
Logic Function: XOR
Mounting Style: SMD/SMT
Output Current: 50 mA
Number of Gates: 1 Gate
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 1.65 V
Number of Input Lines: 2 Input
Number of Output Lines: 1 Output
Pd - Power Dissipation: 1.127 W
Propagation Delay Time: 7.9 ns
Low Level Output Current: 32 mA
High Level Output Current: - 32 mA
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
